Video Amps and Modules
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Package/Case | Series | Packaging | Product Status | Applications | Output Type | Number of Circuits | -3db Bandwidth | Slew Rate | Current - Supply | Current - Output / Channel | Voltage - Supply, Single/Dual (±) | Mounting Type | Grade | Qualification | Supplier Device Package |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
EL5329IREZ-T13BUFFER AMPLIFIER Elantec |
15,000 |
|
Datasheet
|
28-TSSOP (0.173", 4.40mm Width) Exposed Pad | - | Bulk | Obsolete | TFT-LCD Panels: Gamma Buffer, VCOM Driver | Rail-to-Rail | 11 | 10 MHz | 9V/µs | 5.5 mA | 120 mA | 4.5V ~ 16.5V, ±2.25V ~ 8.25V | Surface Mount | - | - | 28-HTSSOP |
|
EL2470CN-02VIDEO AMPLIFIER, 4 CHANNEL(S), 1 Elantec |
5,634 |
|
Datasheet
|
14-DIP (0.300", 7.62mm) | - | Bulk | Active | Current Feedback | - | 4 | 70 MHz | 800V/µs | 1 mA | 55 mA | 3V ~ 12V, ±1.5V ~ 6V | Through Hole | - | - | 14-PDIP |
|
EL2470CS-02VIDEO AMPLIFIER, 4 CHANNEL(S), Elantec |
659 |
|
Datasheet
|
14-SOIC (0.154", 3.90mm Width) | - | Bulk | Active | Current Feedback | - | 4 | 70 MHz | 800V/µs | 1 mA | 55 mA | 3V ~ 12V, ±1.5V ~ 6V | Surface Mount | - | - | 14-SOIC |
|
|
EL5329IRZBUFFER AMPLIFIER Elantec |
490 |
|
Datasheet
|
28-TSSOP (0.173", 4.40mm Width) | - | Tube | Obsolete | TFT-LCD Panels: Gamma Buffer, VCOM Driver | Rail-to-Rail | 11 | 10 MHz | 9V/µs | 5.5 mA | 120 mA | 4.5V ~ 16.5V, ±2.25V ~ 8.25V | Surface Mount | - | - | 28-TSSOP |
|
EL8108ISVIDEO AMPLIFIER Elantec |
14,213 |
|
Datasheet
|
8-SOIC (0.154", 3.90mm Width) | - | Tube | Obsolete | Current Feedback | - | 2 | 200 MHz | 800V/µs | 14.3 mA | 450 mA | 5V ~ 12V, ±2.5V ~ 6V | Surface Mount | - | - | 8-SOIC |
|
|
EL2270CSZELANTEC VIDEO AMPLIFIER Elantec |
23,130 |
|
Datasheet
|
- | EL2270 | Bulk | Obsolete | Current Feedback | Differential | - | 70 MHz | 800V/µs | 1 mA | 60 mA | 1.5V ~ 6V | Surface Mount | - | - | 8-SOP |
|
EL2070CSVIDEO AMPLIFIER, 1 CHANNEL(S), 1 Elantec |
2,194 |
|
Datasheet
|
8-SOIC (0.154", 3.90mm Width) | - | Bulk | Active | Current Feedback | - | 1 | 200 MHz | 700V/µs | 16 mA | 70 mA | ±5V | Surface Mount | - | - | 8-SOIC |
|
EL2357CNVIDEO AMPLIFIER, 3 CHANNEL(S), 1 Elantec |
14,807 |
|
Datasheet
|
16-DIP (0.300", 7.62mm) | - | Bulk | Active | Driver, Video | - | 3 | 125 MHz | 300V/µs | 5 mA | 100 mA | 2.7V ~ 12V, ±1.35V ~ 6V | Through Hole | - | - | 16-PDIP |
|
EL2270CS-T13ELANTEC VIDEO AMPLIFIER Elantec |
25,000 |
|
Datasheet
|
- | EL2270 | Bulk | Obsolete | Current Feedback | Differential | - | 70 MHz | 800V/µs | 1 mA | 55 mA | 1.5V ~ 6V | Surface Mount | - | - | 8-SOP |
|
EL2450CS-T7VIDEO AMPLIFIER, 1 CHANNEL(S), 4 Elantec |
3,935 |
|
Datasheet
|
14-SOIC (0.154", 3.90mm Width) | - | Bulk | Active | Driver, Video | Differential | 4 | 150 MHz | 300V/µs | 5 mA | 100 mA | 2.7V ~ 12V, ±1.35V ~ 6V | Surface Mount | - | - | 14-SOIC |
