Pulse Electronics PE-68411NL

Part No.:
PE-68411NL
Manufacturer:
Pulse Electronics
Category:
Switching Converter, SMPS Transformers
Package:
Datasheet:
IC-MAX.COMPE-68411NL.pdf
Description:
XFMR FLYBACK DC/DC CONV SMD
Quantity:
Payment:
Payment
Shipping:
Shipping

PE-68411NL Information

  • Specifications
  • Product Details
  • Comparison
  • Tags
Product attributes
Attribute value
Manufacturer:
Pulse Electronics
Series:
-
Packaging:
Tray
Product Status:
Obsolete
Type:
For DC/DC Converters
Applications:
Flyback Converters
Intended Chipset:
LM2585, LM2586, LM2587, LM2588
Chipset Manufacturer:
National Semiconductor
Voltage - Primary:
8 ~ 16V
Voltage - Auxiliary:
-
Voltage - Isolation:
1500Vrms
Inductance @ Frequency:
-
Frequency:
-
Operating Temperature:
-40°C ~ 130°C
Grade:
-
Qualification:
-
Mounting Type:
Surface Mount
Size / Dimension:
0.920" L x 1.040" W (23.37mm x 26.42mm)
Height - Seated (Max):
0.480" (12.19mm)
Footprint:
0.920" L x 1.040" W (23.37mm x 26.42mm)
Style:
-
Datasheet:
IC-MAX.COMPE-68411NL.pdf
