QST QPT-0005

Compare

Part No.:: QPT-0005

Manufacturer:: QST

Category:: Wireless Charging Coils

Package:

Datasheet:: QPT-0005.pdf

Description:: Transmitter

Quantity:: Add To Cart Add To RFQ list

Unit Price:$0

Ext Price:$0

Payment:

Shipping:

QPT-0005 Information

Specifications
Product Details
Comparison
Tags

Product attributes: Attribute value

Manufacturer:: QST

Series:: -

Packaging:: Bulk

Product Status:: Active

Function:: Transmitter

Type:: 3 Coil, 1 Layer

Inductance:: 6.8µH, 6.5µH, 6.8µH

Tolerance:: ±10%

DC Resistance (DCR):: 55mOhm

Q @ Freq:: 50 @ 100kHz, 45 @ 100kHz, 50 @ 100kHz

Current Rating (Amps):: -

Current - Saturation (Isat):: -

Frequency - Self Resonant:: -

Operating Temperature:: 0°C ~ 40°C

Size / Dimension:: 4.80" L x 2.13" W x 0.18" H (122.0mm x 54.0mm x 4.5mm)

Datasheet:: QPT-0005.pdf

Part Number	QPT-0036A	QPT-0023	QPT-6071A	QPT-0003	QPT-0039A
Manufacturer	QST	QST	QST	QST	QST
Series	-	-	-	-	-
Packaging	Box	Box	Bulk	Bulk	Box
Product Status	Active	Active	Active	Active	Active
Function	Transmitter	Transmitter	Transmitter	Transmitter	Transmitter
Type	1 Coil, 1 Layer	1 Coil, 1 Layer	1 Coil, 1 Layer	1 Coil, 1 Layer	1 Coil, 1 Layer
Inductance	3.8µH	3.8µH	6.5µH	6.5µH	6.5µH
Tolerance	±10%	±10%	±10%	±10%	±10%
DC Resistance (DCR)	-	-	380mOhm Max	35mOhm	35mOhm
Q @ Freq	-	-	65 @ 100kHz	100 @ 100kHz	65 @ 100kHz
Current Rating (Amps)	-	-	-	-	-
Current - Saturation (Isat)	-	-	-	-	-
Frequency - Self Resonant	-	-	-	-	-
Operating Temperature	-	-	0°C ~ 40°C	0°C ~ 40°C	0°C ~ 40°C
Size / Dimension	2.83" L x 1.97" W x 0.04" H (72.0mm x 50.0mm x 1.0mm)	2.83" L x 1.97" W x 0.04" H (72.0mm x 50.0mm x 1.0mm)	1.97" Dia x 0.09" H (50.0mm x 2.3mm)	2.11" L x 2.11" W x 0.13" H (53.5mm x 53.5mm x 3.3mm)	1.97" Dia x 0.09" H (50.0mm x 2.3mm)
