Isolators - Gate Drivers
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Package/Case | Packaging | Product Status | Technology | Number of Channels | Voltage - Isolation | Common Mode Transient Immunity (Min) | Propagation Delay tpLH / tpHL (Max) | Pulse Width Distortion (Max) | Rise / Fall Time (Typ) | Current - Output High, Low | Current - Peak Output | Voltage - Forward (Vf) (Typ) | Current - DC Forward (If) (Max) | Voltage - Output Supply | Grade | Qualification | Operating Temperature | Mounting Type | Supplier Device Package | Approval Agency |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
PS9402-E3-AXOPTOISO 5KV 1CH GATE DVR 16SSOP Renesas Electronics Corporation |
843 |
|
Datasheet
|
- | 16-SOIC (0.295", 7.50mm Width) | Tape & Reel (TR) | Active | Optical Coupling | 1 | 5000Vrms | 25kV/µs | 200ns, 200ns | 100ns | 50ns, 50ns | 2A, 2A | 2.5A | 1.56V | 25 mA | 15V ~ 30V | - | - | -40°C ~ 110°C | Surface Mount | 16-SSOP | CSA, UL |
|
|
PS9905-Y-V-F3-AXOPTOISO 7.5KV 1CH GT DVR 8LSDIP Renesas Electronics Corporation |
951 |
|
Datasheet
|
- | 8-SOIC (0.543", 13.80mm Width) | Tape & Reel (TR) | Active | Optical Coupling | 1 | 7500Vrms | 25kV/µs | 150ns, 150ns | 75ns | 50ns, 50ns | 2A, 2A | 2.5A | 1.56V | 25 mA | 15V ~ 30V | - | - | -40°C ~ 110°C | Surface Mount | 8-LSDIP | CSA, SEMKO, UL, VDE |
|
PS9531L3-V-AXOPTOISO 5KV 1CH GATE DVR 8SMD Renesas Electronics Corporation |
0 |
|
Datasheet
|
- | 8-SMD, Gull Wing | Tube | Active | Optical Coupling | 1 | 5000Vrms | 50kV/µs | 175ns, 175ns | 75ns | 40ns, 40ns | 2A, 2A | 2.5A | 1.56V | 25 mA | - | - | - | -40°C ~ 125°C | Surface Mount | 8-SMD | CSA, SEMKO, UL, VDE |
.jpg)
|
PS9331L-AXOPTOISO 5KV 1CH GATE DVR 6SDIP Renesas Electronics Corporation |
0 |
|
Datasheet
|
- | 6-SOIC (0.268", 6.80mm Width) | Strip | Not For New Designs | Optical Coupling | 1 | 5000Vrms | 50kV/µs | 175ns, 175ns | 75ns | 40ns, 40ns | 2A, 2A | 2.5A | 1.56V | 25 mA | 15V ~ 30V | - | - | -40°C ~ 125°C | Surface Mount | 6-SDIP Gull Wing | CSA, SEMKO, UL |
|
|
PS9331L2-AXOPTOISO 5KV 1CH GATE DVR 6SDIP Renesas Electronics Corporation |
0 |
|
Datasheet
|
- | 6-SOIC (0.268", 6.80mm Width) | Strip | Not For New Designs | Optical Coupling | 1 | 5000Vrms | 50kV/µs | 175ns, 175ns | 75ns | 40ns, 40ns | 2A, 2A | 2.5A | 1.56V | 25 mA | 15V ~ 30V | - | - | -40°C ~ 125°C | Surface Mount | 6-SDIP Gull Wing | CSA, SEMKO, UL |
|
|
PS9307AL2-AXOPTOISO 5KV 1CH GATE DVR 6SMD Renesas Electronics Corporation |
0 |
|
Datasheet
|
- | 6-SOIC (0.268", 6.80mm Width) | Strip | Not For New Designs | Optical Coupling | 1 | 5000Vrms | 50kV/µs | 150ns, 150ns | 50ns | 30ns, 30ns | 400mA, 400mA | 600mA | 1.56V | 25 mA | 10V ~ 30V | - | - | -40°C ~ 125°C | Surface Mount | 6-SMD | - |
|
|
PS9331L2-V-AXOPTOISO 5KV 1CH GATE DVR 6SDIP Renesas Electronics Corporation |
0 |
|
Datasheet
|
- | 6-SOIC (0.268", 6.80mm Width) | Strip | Not For New Designs | Optical Coupling | 1 | 5000Vrms | 50kV/µs | 175ns, 175ns | 75ns | 40ns, 40ns | 2A, 2A | 2.5A | 1.56V | 25 mA | 15V ~ 30V | - | - | -40°C ~ 125°C | Surface Mount | 6-SDIP Gull Wing | CSA, SEMKO, UL, VDE |
|
|
PS9332L2-V-AXOPTOISO 5KV 1CH GATE DVR 8SDIP Renesas Electronics Corporation |
0 |
|
Datasheet
|
- | 8-SOIC (0.268", 6.81mm Width) | Strip | Not For New Designs | Optical Coupling | 1 | 5000Vrms | 50kV/µs | 200ns, 200ns | 75ns | 17ns, 17ns | 1.5A, 1.5A | 2A | 1.56V | 25 mA | 15V ~ 30V | - | - | -40°C ~ 125°C | Surface Mount | 8-SDIP Gull Wing | CSA, SEMKO, UL, VDE |
|
PS9031-Y-V-AXOPTOISO 5KV 1CH GATE DVR 5LSOP Renesas Electronics Corporation |
1,980 |
|
Datasheet
|
- | 6-SOIC (0.295", 7.50mm Width), 5 Leads | Tape & Reel (TR) | Active | Optical Coupling | 1 | 5000Vrms | 50kV/µs | 175ns, 175ns | 75ns | 40ns, 40ns | 2A, 2A | 2.5A | 1.56V | 25 mA | 15V ~ 30V | - | - | -40°C ~ 125°C | Surface Mount | 5-LSOP | CSA, UL, VDE |
|
PS9905-Y-V-AXOPTOISO 7.5KV 1CH GT DVR 8LSDIP Renesas Electronics Corporation |
0 |
|
- |
- | 8-SOIC (0.543", 13.80mm Width) | Strip | Not For New Designs | Optical Coupling | 1 | 7500Vrms | 25kV/µs | 150ns, 150ns | 75ns | 50ns, 50ns | 2A, 2A | 2.5A | 1.56V | 25 mA | 15V ~ 30V | - | - | -40°C ~ 110°C | Surface Mount | 8-LSDIP | CSA, SEMKO, UL, VDE |
