Trimmers, Variable Capacitors(1700)
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Packaging | Product Status | Capacitance Range | Adjustment Type | Voltage - Rated | Dielectric Material | Q @ Freq | Size / Dimension | Height - Seated (Max) | Operating Temperature | Mounting Type | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
KT15HVCAP TRIMMER 1-15PF 750V PNL MNT |
20 |
|
Datasheet
|
K_HV | Bulk | Active | 1 ~ 15pF | Top | 750 V | Polytetrafluoroethylene (PTFE) | 2000 @ 100MHz | 0.230" Dia (5.84mm) | 0.470" (11.94mm) | -65°C ~ 125°C | Panel Mount | General Purpose |
|
|
5500CAP FILM TRIM |
18 |
|
Datasheet
|
- | Bulk | Active | 1 ~ 20pF | Side | 250 V | Air | 1500 @ 100MHz | 0.490" L x 0.250" W (12.45mm x 6.35mm) | - | -55°C ~ 125°C | Surface Mount | Sealed |
|
5601CAP FILM TRIM |
19 |
|
Datasheet
|
- | Bulk | Active | 1 ~ 30pF | Side | 250 V | Air | 800 @ 100MHz | 0.760" L x 0.160" W (19.30mm x 4.06mm) | - | -55°C ~ 125°C | Surface Mount | Sealed |
|
|
5761CAP FILM TRIM |
10 |
|
Datasheet
|
- | Bulk | Active | 0.6 ~ 6pF | Side | 250 V | Air | 10000 @ 100MHz | 0.290" L x 0.190" W (7.37mm x 4.83mm) | - | - | Surface Mount | Non-Magnetic |
|
|
TP11GCAP FILM TRIM |
5 |
|
Datasheet
|
- | Bulk | Active | 1 ~ 11pF | Side | 1250 V | Glass | 700 @ 1MHz | 0.610" L x 0.440" W (15.49mm x 11.18mm) | - | -55°C ~ 125°C | Through Hole | Sealed |
|
|
TP11CAP FILM TRIM |
21 |
|
Datasheet
|
- | Bulk | Active | 1 ~ 11pF | Side | 750 V | - | 700 @ 1MHz | 0.560" L x 0.440" W (14.22mm x 11.18mm) | - | -55°C ~ 125°C | Through Hole | Sealed |
|
|
QM10GCAP FILM TRIM |
7 |
|
Datasheet
|
- | Bulk | Active | 0.6 ~ 9.5pF | Side | 500 V | Quartz | 2000 @ 1MHz | 1.060" Dia (26.92mm) | - | -55°C ~ 125°C | Panel Mount | General Purpose |
|
|
NMKT10HVCAP FILM TRIM |
3 |
|
Datasheet
|
- | Bulk | Active | 1 ~ 9pF | Side | 1000 V | - | 600 @ 100MHz | 0.310" Dia (7.87mm) | 0.270" (6.86mm) | -65°C ~ 125°C | Panel Mount | General Purpose |
|
|
NMAJ55HVECAP FILM TRIM |
5 |
|
Datasheet
|
NMA | Bulk | Active | 1.5 ~ 55pF | Side | 600 V | - | 780 @ 100MHz | 0.300" Dia (7.62mm) | 1.000" (25.40mm) | -65°C ~ 125°C | Through Hole | General Purpose |
|
|
NMKT15HVCAP FILM TRIM |
2 |
|
- |
- | Bulk | Active | - | - | - | - | - | - | - | - | - | - |
|
GGC4R500CAP TRIMMER 0.8-4.5PF 750V TH |
7 |
|
Datasheet
|
PISTONCAP® | Bulk | Obsolete | 0.8 ~ 4.5pF | Side | 750 V | Glass | 500 @ 20MHz | 0.312" Dia (7.92mm) | 0.312" (7.92mm) | -55°C ~ 125°C | Through Hole | General Purpose |
|
AT 27269CAP TRIMMER 0.3-1.2PF 500V TH |
12 |
|
Datasheet
|
Sapphire Trimmers | Bulk | Active | 0.3 ~ 1.2pF | Top | 500 V | Sapphire | 5000 @ 250MHz | 0.075" Dia (1.90mm) | 0.230" (5.80mm) | -55°C ~ 125°C | Through Hole | General Purpose |
|
AT 27263+CAPCAP TRIMMER 0.3-1.2PF 500V SMD |
6 |
|
Datasheet
|
Sapphire Trimmers | Bulk | Active | 0.3 ~ 1.2pF | Top | 500 V | Sapphire | 5000 @ 250MHz | 0.075" Dia (1.90mm) | 0.230" (5.80mm) | -55°C ~ 125°C | Surface Mount | General Purpose |
|
GGN8R533CAP TRIMMER 0.8-8.5PF 750V SMD |
19 |
|
Datasheet
|
PISTONCAP® | Bulk | Obsolete | 0.8 ~ 8.5pF | Side | 750 V | Glass | 500 @ 20MHz | 0.312" Dia (7.92mm) | 0.673" (17.10mm) | -55°C ~ 125°C | Surface Mount | General Purpose |
|
GUN1R200CAP TRIMMER 0.3-1.2PF 500V TH |
30 |
|
Datasheet
|
PISTONCAP® | Bulk | Obsolete | 0.3 ~ 1.2pF | - | 500 V | Sapphire | 4000 @ 250MHz | 0.075" Dia (1.90mm) | 0.230" (5.80mm) | -55°C ~ 125°C | Through Hole | General Purpose |
|
GUR1R200CAP TRIMMER 0.3-1.2PF 500V TH |
29 |
|
Datasheet
|
PISTONCAP® | Bulk | Obsolete | 0.3 ~ 1.2pF | - | 500 V | Sapphire | 4000 @ 250MHz | 0.075" Dia (1.90mm) | 0.230" (5.80mm) | -55°C ~ 125°C | Through Hole | General Purpose |
|
GUF1R250CAP TRIMMER 0.3-1.2PF 500V TH |
25 |
|
Datasheet
|
PISTONCAP® | Bulk | Obsolete | 0.3 ~ 1.2pF | - | 500 V | Sapphire | 4000 @ 250MHz | 0.075" Dia (1.90mm) | 0.230" (5.80mm) | -55°C ~ 125°C | Through Hole | General Purpose |
|
GEP14000CAP TRIMMER 1-14PF 750V TH |
100 |
|
Datasheet
|
PISTONCAP® | Bulk | Obsolete | 1 ~ 14pF | Top | 750 V | Glass | 500 @ 20MHz | 0.312" Dia (7.92mm) | 0.375" (9.53mm) | -55°C ~ 125°C | Through Hole | General Purpose |
|
GHN23000CAP TRIMMER 0.8-23PF 750V TH |
10 |
|
Datasheet
|
PISTONCAP® | Bulk | Obsolete | 0.8 ~ 23pF | Side | 750 V | Glass | 700 @ 20MHz | 0.312" Dia (7.92mm) | 1.031" (26.19mm) | -55°C ~ 125°C | Through Hole | General Purpose |
|
GNC2R500CAP TRIMMER 0.4-2.5PF 500V TH |
49 |
|
Datasheet
|
PISTONCAP® | Bulk | Obsolete | 0.4 ~ 2.5pF | Side | 500 V | Sapphire | 3000 @ 250MHz | 0.118" Dia (3.00mm) | 0.230" (5.80mm) | -55°C ~ 125°C | Through Hole | General Purpose |
