Bourns Inc. PTVS10-380C-TH
- Part No.:
- PTVS10-380C-TH
- Manufacturer:
- Bourns Inc.
- Category:
- TVS Diodes
- Package:
- Axial, Right Angle Bend (24.15mm Center)
- Datasheet:
-
PTVS10-380C-TH.pdf
- Description:
- TVS DIODE 380VWM 520VC AXIAL
- Quantity:
Unit Price:$0
Ext Price:$0
- Payment:
- Shipping:
PTVS10-380C-TH Information
- Specifications
- Product Details
- Comparison
- Tags
- Product attributes
- Attribute value
- Manufacturer:
- Bourns Inc.
- Package/Case:
- Axial, Right Angle Bend (24.15mm Center)
- Series:
- PTVS
- Packaging:
- Tray
- Product Status:
- Active
- Type:
- Zener
- Unidirectional Channels:
- -
- Bidirectional Channels:
- 1
- Voltage - Reverse Standoff (Typ):
- 380V (Max)
- Voltage - Breakdown (Min):
- 401V
- Voltage - Clamping (Max) @ Ipp:
- 520V (Typ)
- Current - Peak Pulse (10/1000µs):
- 10000A (10kA) (8/20µs)
- Power - Peak Pulse:
- -
- Power Line Protection:
- No
- Applications:
- General Purpose
- Capacitance @ Frequency:
- 1200pF @ 10kHz
- Operating Temperature:
- -55°C ~ 125°C (TJ)
- Grade:
- -
- Qualification:
- -
- Mounting Type:
- Through Hole
- Supplier Device Package:
- Axial
- Datasheet:
-
PTVS10-380C-TH.pdf
| Image |  |
 |
|
|
 |
| Part Number | PTVS10-380C-TH | PTVS10-066C-M | PTVS10-076C-M | PTVS10-320C-TH | PTVS10-058C-TH |
| Manufacturer | Bourns Inc. | Bourns Inc. | Bourns Inc. | Bourns Inc. | Bourns Inc. |
| Package/Case | Axial, Right Angle Bend (24.15mm Center) | 2-SMD, Flat Leads | 2-SMD, Flat Leads | Axial, Right Angle Bend (24.15mm Center) | Axial, Right Angle Bend (24.15mm Center) |
| Series | PTVS | PTVS | PTVS | PTVS | PTVS |
| Packaging | Tray | Tape & Reel (TR) | Tape & Reel (TR) | Tray | Tray |
| Product Status | Active | Active | Active | Active | Active |
| Type | Zener | Zener | Zener | Zener | Zener |
| Unidirectional Channels | - | - | - | - | - |
| Bidirectional Channels | 1 | 1 | 1 | 1 | 1 |
| Voltage - Reverse Standoff (Typ) | 380V (Max) | 66V (Max) | 76V (Max) | 320V (Max) | 58V (Max) |
| Voltage - Breakdown (Min) | 401V | 72V | 85V | 336V | 64V |
| Voltage - Clamping (Max) @ Ipp | 520V (Typ) | 120V | 135V | 440V (Typ) | 110V |
| Current - Peak Pulse (10/1000µs) | 10000A (10kA) (8/20µs) | 10000A (10kA) (8/20µs) | 10000A (10kA) (8/20µs) | 10000A (10kA) (8/20µs) | 10000A (10kA) (8/20µs) |
| Power - Peak Pulse | - | - | - | - | - |
| Power Line Protection | No | No | No | No | No |
| Applications | General Purpose | General Purpose | General Purpose | General Purpose | General Purpose |
| Capacitance @ Frequency | 1200pF @ 10kHz | 6700pF @ 10kHz | 5500pF @ 10kHz | 1400pF @ 10kHz | 7500pF @ 10kHz |
| Operating Temperature | -55°C ~ 125°C (TJ) | -55°C ~ 125°C (TJ) | -55°C ~ 125°C (TJ) | -55°C ~ 125°C (TJ) | -55°C ~ 125°C (TJ) |
| Grade | - | - | - | - | - |
| Qualification | - | - | - | - | - |
| Mounting Type | Through Hole | Surface Mount | Surface Mount | Through Hole | Through Hole |
| Supplier Device Package | Axial | 2-SMD | 2-SMD | Axial | Axial |
