onsemi NCP5369MNTWG
- Part No.:
- NCP5369MNTWG
- Manufacturer:
- onsemi
- Category:
- Full Half-Bridge (H Bridge) Drivers
- Package:
- 40-VFQFN Exposed Pad
- Datasheet:
-
NCP5369MNTWG.pdf
- Description:
- IC HALF BRIDGE DRIVER 35A 40QFN
- Quantity:
Unit Price:$0
Ext Price:$0
- Payment:
- Shipping:
NCP5369MNTWG Information
- Specifications
- Product Details
- Comparison
- Tags
- Product attributes
- Attribute value
- Manufacturer:
- onsemi
- Series:
- -
- Package/Case:
- 40-VFQFN Exposed Pad
- Packaging:
- Tape & Reel (TR)
- Product Status:
- Obsolete
- Output Configuration:
- Half Bridge
- Applications:
- Synchronous Buck Converters
- Interface:
- PWM
- Load Type:
- Inductive
- Technology:
- Power MOSFET
- Rds On (Typ):
- -
- Current - Output / Channel:
- 35A
- Current - Peak Output:
- 50A
- Voltage - Supply:
- 4.5V ~ 5.5V
- Voltage - Load:
- 4.5V ~ 25V
- Operating Temperature:
- -55°C ~ 150°C (TJ)
- Grade:
- -
- Qualification:
- -
- Features:
- Bootstrap Circuit, Status Flag
- Fault Protection:
- Over Temperature, Shoot-Through, UVLO
- Mounting Type:
- Surface Mount
- Supplier Device Package:
- 40-QFN (6x6)
- Datasheet:
-
NCP5369MNTWG.pdf
| Image |  |
| Part Number | NCP5369MNTWG |
| Manufacturer | onsemi |
| Series | - |
| Package/Case | 40-VFQFN Exposed Pad |
| Packaging | Tape & Reel (TR) |
| Product Status | Obsolete |
| Output Configuration | Half Bridge |
| Applications | Synchronous Buck Converters |
| Interface | PWM |
| Load Type | Inductive |
| Technology | Power MOSFET |
| Rds On (Typ) | - |
| Current - Output / Channel | 35A |
| Current - Peak Output | 50A |
| Voltage - Supply | 4.5V ~ 5.5V |
| Voltage - Load | 4.5V ~ 25V |
| Operating Temperature | -55°C ~ 150°C (TJ) |
| Grade | - |
| Qualification | - |
| Features | Bootstrap Circuit, Status Flag |
| Fault Protection | Over Temperature, Shoot-Through, UVLO |
| Mounting Type | Surface Mount |
| Supplier Device Package | 40-QFN (6x6) |
