Renesas Electronics Corporation PS2806-1-F3-A
- Part No.:
- PS2806-1-F3-A
- Manufacturer:
- Renesas Electronics Corporation
- Package:
- 4-SOIC (0.173", 4.40mm Width)
- Datasheet:
-
PS2806-1-F3-A.pdf
- Description:
- OPTOISOLATOR 2.5KV DARL 4SOIC
- Quantity:
Unit Price:$0
Ext Price:$0
- Payment:
- Shipping:
PS2806-1-F3-A Information
- Specifications
- Product Details
- Comparison
- Tags
- Product attributes
- Attribute value
- Manufacturer:
- Renesas Electronics Corporation
- Series:
- NEPOC
- Package/Case:
- 4-SOIC (0.173", 4.40mm Width)
- Packaging:
- Tape & Reel (TR)
- Product Status:
- Not For New Designs
- Number of Channels:
- 1
- Voltage - Isolation:
- 2500Vrms
- Current Transfer Ratio (Min):
- 200% @ 1mA
- Current Transfer Ratio (Max):
- -
- Turn On / Turn Off Time (Typ):
- -
- Rise / Fall Time (Typ):
- 200µs, 200µs
- Input Type:
- AC, DC
- Output Type:
- Darlington
- Voltage - Output (Max):
- 40V
- Current - Output / Channel:
- 90mA
- Voltage - Forward (Vf) (Typ):
- 1.1V
- Current - DC Forward (If) (Max):
- 50 mA
- Vce Saturation (Max):
- 1V
- Grade:
- -
- Qualification:
- -
- Operating Temperature:
- -55°C ~ 100°C
- Mounting Type:
- Surface Mount
- Supplier Device Package:
- 4-SSOP
- Datasheet:
-
PS2806-1-F3-A.pdf
| Image |  |
 |
 |
 |
| Part Number | PS2806-1-F3-A | PS2806-4-A | PS2806-4-F3-A | PS2806-1-A |
| Manufacturer | Renesas Electronics Corporation | Renesas Electronics Corporation | Renesas Electronics Corporation | Renesas Electronics Corporation |
| Series | NEPOC | NEPOC | NEPOC | NEPOC |
| Package/Case | 4-SOIC (0.173", 4.40mm Width) | 16-SOIC (0.173", 4.40mm Width) | 16-SOIC (0.173", 4.40mm Width) | 4-SOIC (0.173", 4.40mm Width) |
| Packaging | Tape & Reel (TR) | Strip | Tape & Reel (TR) | Tube |
| Product Status | Not For New Designs | Not For New Designs | Not For New Designs | Not For New Designs |
| Number of Channels | 1 | 4 | 4 | 1 |
| Voltage - Isolation | 2500Vrms | 2500Vrms | 2500Vrms | 2500Vrms |
| Current Transfer Ratio (Min) | 200% @ 1mA | 200% @ 1mA | 200% @ 1mA | 200% @ 1mA |
| Current Transfer Ratio (Max) | - | - | - | - |
| Turn On / Turn Off Time (Typ) | - | - | - | - |
| Rise / Fall Time (Typ) | 200µs, 200µs | 200µs, 200µs | 200µs, 200µs | 200µs, 200µs |
| Input Type | AC, DC | AC, DC | AC, DC | AC, DC |
| Output Type | Darlington | Darlington | Darlington | Darlington |
| Voltage - Output (Max) | 40V | 40V | 40V | 40V |
| Current - Output / Channel | 90mA | 100mA | 100mA | 90mA |
| Voltage - Forward (Vf) (Typ) | 1.1V | 1.1V | 1.1V | 1.1V |
| Current - DC Forward (If) (Max) | 50 mA | 50 mA | 50 mA | 50 mA |
| Vce Saturation (Max) | 1V | 1V | 1V | 1V |
| Grade | - | - | - | - |
| Qualification | - | - | - | - |
| Operating Temperature | -55°C ~ 100°C | -55°C ~ 100°C | -55°C ~ 100°C | -55°C ~ 100°C |
| Mounting Type | Surface Mount | Surface Mount | Surface Mount | Surface Mount |
| Supplier Device Package | 4-SSOP | 16-SOP | 16-SSOP | 4-SOP |
