STMicroelectronics STG3P2M10N60B
- Part No.:
- STG3P2M10N60B
- Manufacturer:
- STMicroelectronics
- Category:
- IGBT Modules
- Package:
- SEMITOP®2
- Description:
- IGBT MOD 600V 19A 56W SEMITOP2
- Quantity:
Unit Price:$0
Ext Price:$0
- Payment:
- Shipping:
STG3P2M10N60B Information
- Specifications
- Product Details
- Comparison
- Tags
- Product attributes
- Attribute value
- Manufacturer:
- STMicroelectronics
- Series:
- SEMITOP®
- Package/Case:
- SEMITOP®2
- Packaging:
- Bulk
- Product Status:
- Obsolete
- IGBT Type:
- -
- Configuration:
- Three Phase Inverter
- Voltage - Collector Emitter Breakdown (Max):
- 600 V
- Current - Collector (Ic) (Max):
- 19 A
- Power - Max:
- 56 W
- Vce(on) (Max) @ Vge, Ic:
- 2.5V @ 15V, 7A
- Current - Collector Cutoff (Max):
- 10 µA
- Input Capacitance (Cies) @ Vce:
- 720 pF @ 25 V
- Input:
- Single Phase Bridge Rectifier
- NTC Thermistor:
- No
- Operating Temperature:
- -40°C ~ 150°C (TJ)
- Mounting Type:
- Chassis Mount
- Supplier Device Package:
- SEMITOP®2
| Image |  |
| Part Number | STG3P2M10N60B |
| Manufacturer | STMicroelectronics |
| Series | SEMITOP® |
| Package/Case | SEMITOP®2 |
| Packaging | Bulk |
| Product Status | Obsolete |
| IGBT Type | - |
| Configuration | Three Phase Inverter |
| Voltage - Collector Emitter Breakdown (Max) | 600 V |
| Current - Collector (Ic) (Max) | 19 A |
| Power - Max | 56 W |
| Vce(on) (Max) @ Vge, Ic | 2.5V @ 15V, 7A |
| Current - Collector Cutoff (Max) | 10 µA |
| Input Capacitance (Cies) @ Vce | 720 pF @ 25 V |
| Input | Single Phase Bridge Rectifier |
| NTC Thermistor | No |
| Operating Temperature | -40°C ~ 150°C (TJ) |
| Mounting Type | Chassis Mount |
| Supplier Device Package | SEMITOP®2 |
