Vishay Semiconductor Opto Division ILQ621GB-X009
- Part No.:
- ILQ621GB-X009
- Manufacturer:
- Vishay Semiconductor Opto Division
- Package:
- 16-SMD, Gull Wing
- Datasheet:
-
ILQ621GB-X009.pdf
- Description:
- OPTOISO 5.3KV 4CH TRANS 16SMD
- Quantity:
Unit Price:$0
Ext Price:$0
- Payment:
- Shipping:
ILQ621GB-X009 Information
- Specifications
- Product Details
- Comparison
- Tags
- Product attributes
- Attribute value
- Manufacturer:
- Vishay Semiconductor Opto Division
- Series:
- -
- Package/Case:
- 16-SMD, Gull Wing
- Packaging:
- Tube
- Product Status:
- Active
- Number of Channels:
- 4
- Voltage - Isolation:
- 5300Vrms
- Current Transfer Ratio (Min):
- 100% @ 5mA
- Current Transfer Ratio (Max):
- 600% @ 5mA
- Turn On / Turn Off Time (Typ):
- 3µs, 2.3µs
- Rise / Fall Time (Typ):
- 2µs, 2µs
- Input Type:
- DC
- Output Type:
- Transistor
- Voltage - Output (Max):
- 70V
- Current - Output / Channel:
- 50mA
- Voltage - Forward (Vf) (Typ):
- 1.15V
- Current - DC Forward (If) (Max):
- 60 mA
- Vce Saturation (Max):
- 400mV
- Grade:
- -
- Qualification:
- -
- Operating Temperature:
- -55°C ~ 100°C
- Mounting Type:
- Surface Mount
- Supplier Device Package:
- 16-SMD
- Datasheet:
-
ILQ621GB-X009.pdf
| Image |  |
 |
|
|
 |
| Part Number | ILQ621GB-X009 | ILQ621GB | ILQ621GB-X001 | ILQ621GB-X017T | ILQ621GB-X016 |
| Manufacturer | Vishay Semiconductor Opto Division | Vishay Semiconductor Opto Division | Vishay Semiconductor Opto Division | Vishay Semiconductor Opto Division | Vishay Semiconductor Opto Division |
| Series | - | - | - | - | - |
| Package/Case | 16-SMD, Gull Wing | 16-DIP (0.300", 7.62mm) | 16-DIP (0.300", 7.62mm) | 16-SMD, Gull Wing | 16-DIP (0.400", 10.16mm) |
| Packaging | Tube | Tube | Tube | Tape & Reel (TR) | Tube |
| Product Status | Active | Active | Last Time Buy | Active | Obsolete |
| Number of Channels | 4 | 4 | 4 | 4 | 4 |
| Voltage - Isolation | 5300Vrms | 5300Vrms | 5300Vrms | 5300Vrms | 5300Vrms |
| Current Transfer Ratio (Min) | 100% @ 5mA | 100% @ 5mA | 100% @ 5mA | 100% @ 5mA | 100% @ 5mA |
| Current Transfer Ratio (Max) | 600% @ 5mA | 600% @ 5mA | 600% @ 5mA | 600% @ 5mA | 600% @ 5mA |
| Turn On / Turn Off Time (Typ) | 3µs, 2.3µs | 3µs, 2.3µs | 3µs, 2.3µs | 3µs, 2.3µs | 3µs, 2.3µs |
| Rise / Fall Time (Typ) | 2µs, 2µs | 2µs, 2µs | 2µs, 2µs | 2µs, 2µs | 2µs, 2µs |
| Input Type | DC | DC | DC | DC | DC |
| Output Type | Transistor | Transistor | Transistor | Transistor | Transistor |
| Voltage - Output (Max) | 70V | 70V | 70V | 70V | 70V |
| Current - Output / Channel | 50mA | 50mA | 50mA | 50mA | 50mA |
| Voltage - Forward (Vf) (Typ) | 1.15V | 1.15V | 1.15V | 1.15V | 1.15V |
| Current - DC Forward (If) (Max) | 60 mA | 60 mA | 60 mA | 60 mA | 60 mA |
| Vce Saturation (Max) | 400mV | 400mV | 400mV | 400mV | 400mV |
| Grade | - | - | - | - | - |
| Qualification | - | - | - | - | - |
| Operating Temperature | -55°C ~ 100°C | -55°C ~ 100°C | -55°C ~ 100°C | -55°C ~ 100°C | -55°C ~ 100°C |
| Mounting Type | Surface Mount | Through Hole | Through Hole | Surface Mount | Through Hole |
| Supplier Device Package | 16-SMD | 16-DIP | 16-DIP | 16-SMD | 16-DIP |
